IntroFCCU
Overview
FCCU (Fluid Catalytic Cracking Unit) converts high-octane petrochemical products such as LPG and Gasoline by exposing high molecular weight (heavy) hydrocarbons in crude oil to Fluid Catalytic (fluidized catalyst) refining facility.
The raw material and fluidized catalyst repeatedly fed through the Reactor-Regenerator-Riser are circulated at a very high speed in a high-temperature environment, which causes continuous wear of the lining installed inside the facility.
Since the fire-resistance linings of major containers and refractory linings in transfer line often require periodic maintenance every turn around. Therefore, to improve the run length of equipment by reducing the number of repairs for refractories, above all else, it is essential to construct a refractory lining that has excellent abrasion resistance while minimizing energy loss.
Available Service
Section & Material
Section | Lining | Material |
PLENUM | EXTREME ABRASION RESISTANT CASTABLE | PETROGARD XMA PLUS ACTCHEM 85 |
FORMULA 12 L | ||
PLIRAM 3-25 | ||
MEDIUM WEIGHT INSULATING CASTABLE | LITE WATE 80 LITE WATE 80 G | |
HEATBRAKE 508-B HEATBRAKE 508-G | ||
PLIGUN 3-24 | ||
REGENERATOR / REACTOR EXTERNAL WALL | LIGHT WEIGHT INSULATING CASTABLE | LITE WATE 23/58 LI LITE WATE 23/58 G |
THERMBRAKE 403 THERMBRAKE 403-G | ||
PLIGUN LW 3-22A PLIGUN LW 3-23 | ||
REACTOR INTERNAL WALL | MEDIUM WEIGHT INSULATING CASTABLE | AR 153 G LITE WATE 80 G |
HEATBRAKE 508-G | ||
PLIGUN 3-24 | ||
TRANSFER LINE | ABRASION RESISTANT INSULATING CASTABLE | ACTCHEM 45 VC ACTCHEM 45 G |
FORMULA 6 AL | ||
REGENERATOR CYCLONE | ABRASION RESISTANT PLASTIC/RAMMING | 90-RAM HS |
FORMULA 12 L | ||
PLIRAM CYCLONE MIX |
Application
